SNE10BK
Bracket made of AISI 304 stainless steel.
Double ballraces swivel head strongly riveted together as one piece.
NY Injection Polyamide 6 Wheel
Wheel made by injection of high quality nylon 6.
High load capacity,low rolling resistance,high impact strength,good abrasion resistance.
Temperature range - 20°C to + 80°C.
Max.working speed 4km/h.
mm
|
mm
|
mm
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
kg
|
|
|
|
| 80 | 32 | 12 |  |
105x85 | 82x62/78x58 | 9 | 105 | 40 | 200 | SNE10NY081XPF | SN011NY081XPF | SNE10NY081XPF-AQ |
| 80 | 32 | 12 |  |
105x85 | 82x62/78x58 | 9 | 105 | 40 | 200 | SNE10NY081XRF | SN011NY081XRF | SNE10NY081XRF-AQ |
| 80 | 32 | 8 |  |
105x85 | 82x62/78x58 | 9 | 105 | 40 | 200 | SNE10NY081XBD | SN011NY081XBD | SNE10NY081XBD-AQ |
| 100 | 36 | 12 |  |
105x85 | 82x62/78x58 | 9 | 128 | 40 | 200 | SNE10NY102XPF | SN011NY102XPF | SNE10NY102XPF-AQ |
| 100 | 36 | 12 |  |
105x85 | 82x62/78x58 | 9 | 128 | 40 | 200 | SNE10NY102XRF | SN011NY102XRF | SNE10NY102XRF-AQ |
| 100 | 36 | 8 |  |
105x85 | 82x62/78x58 | 9 | 128 | 40 | 200 | SNE10NY102XBD | SN011NY102XBD | SNE10NY102XBD-AQ |
| 125 | 37 | 13 |  |
105x85 | 82x62/78x58 | 9 | 156 | 40 | 200 | SNE10NY125XPF | SN011NY125XPF | SNE10NY125XPF-AQ |
| 125 | 37 | 12 |  |
105x85 | 82x62/78x58 | 9 | 156 | 40 | 200 | SNE10NY125XRF | SN011NY125XRF | SNE10NY125XRF-AQ |
| 125 | 37 | 8 |  |
105x85 | 82x62/78x58 | 9 | 156 | 40 | 200 | SNE10NY125XBD | SN011NY125XBD | SNE10NY125XBD-AQ |
