020BK
Bracket made of pressed steel zinc plated blue passivated finished.
Double ballraces swivel head with hardened raceways.
NY Injection Polyamide 6 Wheel
Wheel made by injection of high quality nylon 6.
High load capacity,low rolling resistance,high impact strength,good abrasion resistance.
Temperature range - 20°C to + 80°C
Max.working speed 4km/h.
mm
|
mm
|
mm
|
|
mm
|
mm
|
mm
|
mm
|
mm
|
kg
|
|
|
|
| 65 | 36 | 15 |  |
64x92 | 41x71/78 | 9 | 91 | 31.5 | 90 | 020NY067PG | 021NY067PG | 020NY067PG-AQ |
| 75 | 32 | 15 |  |
64x92 | 41x71/78 | 9 | 108 | 34 | 200 | 020NY078PG | 021NY078PG | 020NY078PG-AQ |
| 100 | 36 | 15 |  |
64x92 | 41x71/78 | 9 | 130 | 34 | 250 | 020NY100PG | 021NY100PG | 020NY100PG-AQ |
| 100 | 36 | 10 |  |
64x92 | 41x71/78 | 9 | 130 | 34 | 250 | 020NY100BE | 021NY100BE | 020NY100BE-AQ |
| 125 | 37 | 15 |  |
64x92 | 41x71/78 | 9 | 157 | 41 | 250 | 020NY124PG | 021NY124PG | 020NY124PG-AQ |
| 125 | 37 | 10 |  |
64x92 | 41x71/78 | 9 | 157 | 41 | 250 | 020NY124BE | 021NY124BE | 020NY124BE-AQ |
